Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
  • Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part
Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part

Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part

Place of Origin China
Brand Name FQ
Model Number FQ-Moldel Rubber Parts
Product Details
Type:
Moldel Rubber Parts
Shape:
Customizable
Color:
Customizable
Production Capacity:
10000pieces/Month
Packing:
Plastic Bags And Ctn
Feature:
Buffering
Sample:
Freely Offered
Service:
OEM ODM
Highlight:

Molded Rubber Part

,

Rubber Gasket Seal

,

Diaphragm Grommet O Ring

Payment & Shipping Terms
Minimum Order Quantity
500
Price
custom
Packaging Details
Carton
Delivery Time
5-8 work days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
10000 pcs per month
Product Description

Rubber Gasket Seal Diaphragm Grommet O Ring Molded Rubber Part

Product Description

Rubber bushing/rubber stopper/rubber shock absorber is vulcanized with various of material, such as EPDM, NR,SBR etc.
With Good resistance to seasonality, heat resistance, chlorination resistance, aging resistance.
Inside stainless steel and It has a very good damping effect.
Are widely applied in any area, such as furniture, Chassis instrument etc

Production Description
Item Name Rubber bushing, ruubber stopper, rubber shock absorber
Material EPDM,NBR,NR,SBR,PVC,EPT, PP/ABS
Color Black, white, red,etc
Dimension As client's requirement
Hardness 30~90ShA
Feature High elasticity, insulation, abrasion resistance, oil resistance, aging resistance, high temperature resistance, cold resistance, anti-corrosion, anti-static
Application Removable instruction,furniture,etc
OEM welcome
MOQ Meet your requirement
Certification REACH, ROHS,FDA,SGS,etc
Rubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber PartRubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber PartRubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber Part
The advantage and property of rubber bushing/rubber stopper/rubber shock absorber
1.We adopt heighten new technology craft
2.The material of rubber bushing is complete fresh and tasteless
3.Not fade, anti-slip wear-resistant anti - pressure , damping, acid and alkali resistant
4. Environment friendly
Rubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber Part

Rubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber PartRubber Gasket Seal Rubber Product Diaphragm Grommet O Ring Molded Rubber Part
The different material of rubber bushing will cause different property.
EPDM/NBR/silicone/SBR/PP/PVC etc.

Items EPDM NR silicone PVC
Hardness
(Sha)		 30~85 30~90 20~85 50~95
Tensile strength
(Mpa)		 ≥8.5MPa > 20 Mpa 3~8 10~50
Elongation(%) 200~550 1000% 200~800 200~600
Specific Gravity 0.75-1.6 1.15-1.21 1.25~1.35 1.3~1.7
Temperature range -40~+120°C -50~70ºC. -55~+350°C -29°C - 65.5°C
1. the property of NR
It has good wear resistance, high elasticity, breaking strength and elongation, But in the air, it is easy to get age, and it is get sticky when it get in touch with heat, which is easy to expand and dissolve in mineral oil or gasoline, but it is resistant to strong acid, but not to Alkali . working temperature is -50~70ºC.
2. the property of EPDM
Weather ability, aging resistance, ozone resistance, chemical stability are excellent, and CFCS and a variety of refrigerants. Working temperature is -50~150
3. the property of silicone
It has excellent heat resistance, cold resistance, ozone resistance and atmospheric aging resistant.Good electrical insulation performance,The tensile strength and wear resistance are generally poor and has non- oil resistant. The working temperature is -55~250ºC
4. The property of NBR
Good oil resistance, heat resistance, abrasion resistance, solvent resistance and high - pressure oil,But it is not suitable for polar solvents, such as ketones, ozone, nitro-hydrocarbons, and chloroform. The working temperature is -40~120 ºC
5. the property of CR
It has good elasticity, wear resistance and atmospheric aging resistance. It is not afraid of violent distortion and flammability.Chemical stability. The working temperature is -40~100 ºC
6. The property of FKM
Excellent high temperature resistance,And have excellent chemical resistance, most oil and solvent (other than ketones and esters).cold resistance is not good.
